SDM-72 Portable Steel Dust In Grease Meter
SDM-72 Portable Steel Dust In Grease Meter
The SDM-72 Portable Steel Dust In Grease Meter is useful for trend monitoring of wear conditions of bearings, gears etc. The meter is simple to operate and provides simple diagnosis for the monitoring of steel dust contamination in grease.
Applications
- Simple diagnosis and trend monitoring of the wear condition of greased bearings, gears, etc.
- Pre-diagnosis for Ferrography method and SOAP method
Features
- Able to diagnose the bearing condition, even long before wear-induced vibration becomes detectable, by measuring the amount of steel dust in the grease around the bearing.
- Simple operation – simply measured by a grease sample
- Light weight
- Low power consumption- up to 30 hours by alkaline cells
Specifications
| Model | SDM-72 |
| Measurement Principle | Magnetic balance type electromagnetic method |
| Substance Measured | Steel dust concentration in grease |
| Measurement Range | 0 to 5.000 %Wt |
| Minimum Resolusion | 0.001 %Wt |
| Zero adjustment | Automatic adjustment |
| Amount of sample | Approx. 0.8ml |
| Power Source | 4 x AA (R6) alkaline drycells |
| Battery Life*1 | Up to 30 hours by alkaline cells |
| Operating temperature | 0 to +40 °C |
| Dimensions | W84 x H190 x D40 mm |
| Weight | Approx. 500g (including batteries) |
| Standard Accessories | Carrying case, grease sampling spatula, grease sample case (10 pieces) and 4 x AA (R6) alkaline drycells |
*1 Battery life may vary with ambient conditions, conditions of use, storage period, battery manufacturers, etc.
