SDM-73 Portable Steel Dust in Oil Checker
SDM-73 Portable Steel Dust in Oil Checker
The SDM-73 Portable Steel Dust In Oil Meter is useful for trend monitoring of wear conditions of bearings, gears etc. The meter is simple to operate and provides simple diagnosis for the monitoring of steel dust contamination in hydraulic oil.
Applications
- Simple diagnosis of the wear condition of bearings, gears, cylinders, etc. in rotational equipment
- Monitoring steel dust contamination in hydraulic oil and grinding oil
Features
- Able to diagnose the bearing condition, even long before wear-induced vibration becomes detectable, by measuring the amount of steel dust in the oil around the bearing.
- Simple operation – simply measured by an oil sample
Specifications
| Model | SDM-73 |
| Measurement Principle | Magnetic balance type electromagnetic industion method |
| Substance Measured | Steel dust concentration in lubricating oil |
| Measurement Range | 0 to 19999wt ppm |
| Minimum Resolusion | 1wt ppm |
| Zero adjustment | Automatic adjustment |
| Amount of sample | 1.5ml |
| Power Source | 4 x AA (R6) alkaline drycells |
| Battery Life*1 | Up to 30 hours by alkaline cells |
| Operating temperature | 0 to 40 °C |
| Dimensions | W84 x H190 x D40 mm |
| Weight | Approx. 500g (including batteries) |
| Standard Accessories | Carrying case, 2ml syringe (5 pieces), oil sampling nozzle (2 pieces),
syringe holder and 4 x AA (R6) alkaline drycells |
*1 Battery life may vary with ambient conditions, conditions of use, storage period, battery manufacturers, etc.
